SIP Airmate TN5.5/200 Air Compressor (3ph) c/w Anti Vibs
SKU: SIP06583
£1,499.99 incl VAT£1,249.99 excl VAT
In stock
The SIP TN5.5/200 is a trade belt-driven compressor boasting a 2-stage pump for greater efficiency than other models, a heavy-duty cast iron barrel, and full oil lubrication. Ideal for trade use.
Table of Contents
Description
Back to TopSIP Airmate TN5.5/200 Air Compressor (3ph) c/w Anti Vibs info:
- 400v (20A), 3PH input supply
- Powerful 5.5hp (4.1kW) motor
- Oil-lubricated, belt-driven model
- Heavy-duty 200 litre air receiver size
- 24CFM maximum piston displacement
- 18CFM maximum free air delivery (FAD)
- 145psi (10 bar) max. working pressure
- 2-stage pump for a greater efficiency
- Ideal for heavy and prolonged tasks
- Supplied with anti-vibration mounts
- Super heavy-duty cast iron barrel
- Shock-resistant flywheel guard
- Premium Italian construction
Tech Specs
Back to TopInput Supply | 400v (20amp) 3PH |
Motor Power | 5.5hp (4.1kW) |
Receiver Size | 200 litres |
Piston Displacement | 24CFM (680 litres/min) |
Max. Free Air Delivery | 18CFM (510 litres/min) |
Maximum Pressure | 145psi (10 bar) |
No. of Cylinders | 2 cylinders |
No. of Stages | 2 stages |
Gross Weight | 145kg |
Packaged Dimensions | 1140 x 550 x 1500mm |
General Info
Brand |
---|
SKU: | SIP06583 |
---|---|
Category: | Belt Compressors |
Equipment Dimensions
Back to TopWarranty
Back to TopThe warranty period on SIP products is 12 months unless stated otherwise (excludes items designated for hiring purpose, which carry a 3 month warranty). The SIP policy is to repair and return all goods; the option to replace the item(s) remains at entirely at the discretion of SIP.
Delivery
Back to TopFree UK delivery on tools and consumables if order value is over £50.00 (excluding VAT).
Delivery for large goods i.e. Garage Equipment is calculated at the basket.
